Features And Optional Configuration
1. World leading two-stroke engine provides powerful and efficient cutting.
2. Execllent high strength shock-resistant design makes wood-working easy.
3. Exclusive fuel-efficient design, low fuel consumption and high efficiency, save money and labor.
4. Strengthened 32mm rod and stable structure enable long-lasting and highly efficient working.
5. Easy starter device facilitates the starting of the machine.
6. Material of superior quality makes machine durable.
Model NO. | NTB520QL |
Power type | Single Cylinder, Two-stroke, Air-cooling |
Matchengine | 1E44FB |
Cylinder displacement (cc) | 51.7cc |
Power output (kW/hp/rpm) | 1.6kW/2.1hp/7500rpm |
Max engine speed with cutting attachment (r/min) | 9000r/min |
Carburetor type | Rotary valve |
Nylon cutting (ømm) | 415mm |
Diameter of AI. pipe | 32mm |
Fuel capacity | 900ml (31.7 oz.) |
Fuel mixture ratio | 25:1(Gasoline 25 : Two-cycle Oil 1) |
Ignition system | Digital |
Dry weight (excl. cutting equipment) | 9kg (20 lbs.) |
Gross weight | 10.9kg (24 lbs.) |
