Model NO. | NTB330B |
Power type | Single Cylinder, Two-stroke, Air-cooling |
Matchengine | 1E36F-2B |
Cylinder displacement (cc) | 32.6cc |
Power output (kW/hp/rpm) | 0.9kW/1.2hp/7000rpm |
Max engine speed with cutting attachment (r/min) | 9000r/min |
Carburetor type | Rotary valve |
Nylon cutting (ømm) | 2.5mm |
Diameter of AI. pipe | 26mm |
Fuel capacity | 750ml (26.4 oz.) |
Fuel mixture ratio | 25:1(Gasoline 25 : Two-cycle Oil 1) |
Ignition system | Digital |
Dry weight (excl. cutting equipment) | 8.5kg (18.7 lbs.) |
Gross weight | 10kg (22 lbs.) |
